How To Replace Jeep 2.5 Oil Pan Gasket

Replacing a Jeep Wrangler 2.5L Oil Pan Gasket isn't that hard, and will only take a few hours. The hardest part of installing a pan gasket is probably the cleanup on the pan and clean the Jeep 2.5L engine pan surface. The funniest part of this project was me watching my son do it all. FEL-PRO 2.5L Oil Pan Gasket Set: https://amzn.to/3n42Qq6 For most 4x4 Jeeps you won't have to left it or have anything impede your access to the oil pan. Make sure the undercarriage is clean on the jeep, nothing like getting dirt in your eyes or engine. Before you start the oil pan gasket replace, disconnect the battery. You will have to remove the started and if the battery is connected you will get a direct battery short. We remove the ground to the battery, also we had to drain the amp cap before starting. Removing the starter is only two bolts and some wires. Start by removing the wires off the starter. Take note of where each wire terminates, you will have to put them back on. Then you may have some struggles getting the starter out, just takes time and determination. Now on to the flywheel cover on the Jeep 2.5L. Be sure to hold on to this before you remove that last bolt, this falling on you could leave a mark. Removing the flywheel cover you will probably need a bigger wrench, these bolts are on there. In our video, you will see us struggle to remove these. Once the Jeep flywheel cover is off it's a great time to clean up behind where the flywheel is. Taking off the pan you are going to find that the bolts are easy to remove, well they are only torqued down to a max of 11 ft-lb. Make sure that when removing the oil pan bolts to know where they go back for installation. Once all the bolts are out the oil pan and oil pan strap on the back may fall down so be ready for it. If it does fall you may have to smack it on the side to break the oil pan free. With the pan off it is a great time to check for the metal in your pan. This will help you determine how much wear you have on your engine. To check for metal in the oil pan all you need is a magnet. Then stick the magnet in the bottom of the pan and hope it doesn't pick up metal. Once you are sure your Jeep 2.5L is worth repairing you must clean the surfaces. For scraping the flat surfaces, we used a gasket scraper and a razor. We don't use a wire grinder, this can scare the machined surfaces. After the surface are scraped clean, take a rag and soapy water and wipe the gasket surfaces down. This will help the gasket silicone stick. When you are ready to put the gasket in place we put a little extra silicone in the corners. The corners on most oil pan gaskets are where they tend to leak. We then applied a thin layer of silicone to the rest of the pan gasket. Too much silicone can cause issues if it squeezes out inside the engine and clogs oil passages.
