Building a 2,000-Watt Waterproof Subwoofer Box: The Ultimate Jeep DIY
Stop settling for weak bass and rotting enclosures; this forensic build delivers 100% waterproof low-end that won’t quit. A waterproof subwoofer box is the only way to ensure your Jeep’s audio system survives the elements without sacrificing the 30Hz–80Hz “boom” you need.
Primary Data: Technical Baseline & Constraints
- Vessel/Vehicle: Jeep Wrangler (Custom Rear Configuration)
- Subwoofer: 10-inch Skar SVR-10 (High Excursion)
- Power Handling: 2,000 Watts Peak / 1,000 Watts RMS
- Tuning Range: 30Hz – 80Hz (Peak at 80Hz)
- Enclosure Volume: 2.0+ Cubic Feet
- Dimensions: 16″ H x 30″ W x 9″ D
- Port Specs: Dual 20-inch side-firing ports
- Materials: Recycled marine-grade plywood (from the Boat Floor project), exterior house paint applied with a perforated roller.
The Build Strategy: From Boat Floor to Bass Beast
The previous box was too thin, causing massive air noise and “swishing” through the ports. To fix this, we repurposed marine-grade plywood—the same high-density material used during our full boat floor restoration. This provides the rigidity needed for a high-excursion sub pushing 2,000 watts.
We utilized a metal-cutting blade in the jigsaw for the main circle cut to prevent splintering. To achieve that rugged “bedliner” look without the professional cost, we used a perforated roller (the same one used for Kiwi Grip on the boat) to apply thick exterior house paint. This southern technical hack provides a waterproof, high-grip finish that stands up to the Florida humidity and the occasional rain shower in the Jeep.
🛠️ The Forensic Shop Gap: Recommended Tools & Parts
- Subwoofer: Skar SVR 10 – High-excursion beast for deep low-end.
- Cutting: JigSaw – Use a metal blade for clean, non-splintered cuts in marine plywood.
- Assembly: Gorilla Wood Glue – Essential for airtight structural integrity.
- Fasteners: Milwaukee 2691-22 18-Volt Compact Drill and Impact Driver – The standard for driving heavy screws into dense marine wood.
Amazon Affiliate Disclaimer: As an Amazon Associate, I earn from qualifying purchases. This helps support the Crew and future builds.
Check Out Past Projects
- Marine Floor Restoration: See where this plywood came from during our full boat restore.
- Jeep Muffler Install: The two-stage muffler that Danielle says is too loud for the garage.
- Kiwi Grip Application: Mastering the texture roller technique used on this box.
FAQ: Jeep Waterproof Audio
Q: Will regular plywood hold up in a Jeep if it gets rained on?
A: Negative. Standard plywood will delaminate and rot within a season. We use marine-grade plywood recycled from boat projects and seal it with multiple layers of exterior-grade paint. This creates a forensic barrier against moisture while maintaining the structural integrity required for 2,000-watt vibrations.
Q: How do I stop my subwoofer box from sliding around in the back?
A: At 10Hz to 30Hz, the kinetic energy will move an unbolted box. You must bolt the enclosure directly to the Jeep’s floor or roll cage brackets. During our testing, the box moved significantly until secured, which can lead to wire fatigue or terminal failure.
Q: Why use dual side-firing ports instead of rear-firing?
A: Air noise. High-excursion subs like the Skar SVR-10 move massive amounts of air. By running dual 20-inch ports to the sides, we eliminate the “swishing” sound often heard when ports fire directly into a seat or tailgate, allowing the 30-80Hz range to breathe properly.
Q: What is the best way to seal the speaker to the box?
A: Use standard foam weather stripping around the mounting diameter. Don’t rely on the speaker’s built-in gasket alone. Apply the stripping, then use the Milwaukee Impact Driver to compress the seal, ensuring a 100% airtight and waterproof connection.
Support & Connect
- Ho Maid Chef®: Check out Danielle’s latest recipes for the Crew at www.chrisdoeswhat.com/dining-in-with-danielle/
- Jeep DIY: Find more forensic mechanical guides at www.chrisdoeswhat.com/diy/jeep-diy/
- JOIN the Crew: Get exclusive access and support the channel: https://www.youtube.com/channel/UCZBmn0CZW578hpt4ImB3CRA/join
To jump to points in this video:
- 1:30 What we don’t like about the old Skar SVR 10 box
- 2:44 Port location on subwoofer box for the best bass
- 3:53 Building the Jeep Subwoofer Box for the Skar SVR
- 5:37 Installing Port for Subwoofer Box with Skar SVR 10
- 6:59 How To cut a speaker hole in a box.
- 8:15 Putting in the Skar Subwoofer in a ported box.
- 8:57 Creating texture with normal paint for the Skar SVR subwoofer box
- 9:43 Wiring and Sealing our Skar SVR Subwoofer in the custom box
- 11:23 Testing Frequency Response of the Skar SVR Subwoofer In our Custom Box
- 12:18 The dimensions of custom subwoofer box for the Skar SVR 10
- 12:42 Our final thoughts of the Skar SVR 10 Sub and Custom Box
